钰泰选型表

升压稳压器

Part No

Description

Architecture

Vin Min(V

Vin Max(V)

out Min(V)

Vout Max(V)

Isw Max(A)

VIbV

Switchin
H7

lq(uA)

Package

Comment

备注

ETA1032

Fixed 5V Vout Sync.Boos

Sync.True-shutoff

2.5

5.25

2.5M

CSP1.2x1.2-9

5V fixed output with Li+battery

真关断，固定5V输出，NFC应用/通用应用，兼
容TPS61256

ETA1036

Fixed Vout Sync.Boost

Sync.True-shutoff

0.6

4.5

2.1

1.5

SOT23-5

3W output power with Li+battery

真关断，输出电压2.1V/3.3V/5V

ETA1038

5V/1.5A Sync.Boost

Sync.True-shutoff

1.8

4.5

1.8

2.8

1.17

SOT23-6

5V/1.5A ouput with Li+battery

真关断，锂电升压5V输出1.5A,输出电压可调

ETA1039

5V/1.5A Sync.Boost

Sync.True-shutoff

1.8

4.5

Adjustable

SOT23-6

Fixed 5V with 1.5A output with Li+battery

真关断，锂电升压固定5V输出，限流可调

ETA1043

14V/100mA Sync.Boost

Sync.True-shutoff

2.5

6.5

0.8

0.2/0.8

1.2M

DFN2x2-8

14V Sync.Boost/OLED/LED driver for
wearable/IO

14V同步真关断升压/OLED/LED驱动

ETA1060

1.2uA lq,>2W output

Sync.True-shutoff

0.6

1.11

1.4M

1.2

SOT23-6/DFN2x2-6

Ultra low lq

1.2uA工作电流，穿戴设备，NBIOT物联网

ETA1061

1uAla>2W outpu

Sync.True-shutoff

0.55

1.11

1.4M

SOT23-6/DFN2x2-6

Ultra low lq with true-shutoff

1uA工作电流，穿戴设备，NBIOT物联网，兼容
TPS61099

ETA1062

1.2uA la>2W output

Sync.True-shutoff

0.6

3.3/5

1.4M

1.2

SOT23-5

JItra low la with true-shutoff,Fixed 3.3V/5\
output

.2uA工作电流，穿戴设备，NBIOT物联网

ETA1064

1uAla.>2W output

Sync.True-shutoff

0.55

1.11

1.4M

SOT23-6/DFN2x2-6

Ulra low lg with true-shutoff

1uA工作电流，穿戴设备，NBIOT物联网

ETA1066

Boost with 12V LDO

Sync.True-shutoff

1.8

2.2

1.045

900K

180

DFN2x2-8

Dual Outputs with LDO and Boost

PLC模块，后备系统电源等

ETA1067

ost with 12V LD(

Sync.True-shutoff

1.8

2.2

1.05

900K

180

DFN2x2-8

Dual Outputs with LDO and Boost

PLC模块，后备系统电源等

ETA1069

1.2uA lq,>3W output

Sync.True-shutoff

0.75

5.5

0.94

1.6

0.94

1.2

SOT23-6/DFN2x2-6

Ultra low lq with true-shutoff

1.2uA工作电流，穿戴设备，NBIOT物联网

ETA1090

5V High Current Sync.Boost

Sync.True-shutoff

1.8/3.1

5.5

1.8/3.1

Adjustable

0.6

DFN3x3-12

For 3G/4G module and general purpose

真关断，大电流通用升压

ETA1092

5V/3A Sync.Boost

Sync.True-shutoff

1.8/3.1

5.5

1.8/3.1

Adjustable

0.6

QFN3x3-16

Freq.jitter mode available

UVLO电压可配置，抖频模式可选，各类通讯模
块

ETA1093

5V/3A Forced PWM Sync.Boost

Sync.True-shutoff

1.8/3.1

5.5

1.8/3.1

Adjustable

0.6

10mA

QFN3x3-16

BC1.2,Apple 2.4A,Samsung compatible

真关断，BC1.2锂电池升压5V/3A,纯PWM

ETA1096

5V/3A Sync.Boos

Sync.True-shutoff

1.8

5.5

1.8

Adjustable

0.6

ESOP8

For general purpose

真关断，锂电池升压5V/3A,通用升压

ETA1132

Fixed 5.4V Vout Sync.Boost

Sync.True-shutoff

2.5

5.25

5.4

2.5M

CSP1.2x1.2-9

5.4V fixed output

真关断，固定5.4V输出，NFC应用/通用应用
兼容PCA9412A

ETA1133

Fixed 5.4V Vout Sync.Boost

Sync.True-shutoff

2.5

5.25

5.4

2.5M

CSP1.2x1.2-9

54V fixed outpu

真关断，固定5.4V输出，NFC应用/通用应用

ETA1136

5V/1.5A Sync.Boost

Sync.True-shutoff

1.8

4.5

2.8

SOT23-5

Fixed 5V with 1.5A output with Li+battery

真关断，锂电升压固定5V输出1.5A

ETA1188

9V/3A Sync.Boost

Sync.True-shutoff

2.7

3.6

Adjustable

1.2

450K

200

FCQFN3x3-20

High power with l2C control

真关断，大功率，智能音响等

ETA1189

9V/3.5A Sync.Boost

Sync.True-shutofl

3.1

9.5

3.6

12.6

Adjustable

1.2

500K/1000K

200

FCQFN3x3-20

High power with I2C control

真关断，大功率，智能音响等

ETA1611

22V/2A Non-Sync.Boost

Non-Sync

2.7

Vin

2.8

0.2

250

SOT23-6

High Output Voltage

高输出电压，通用升压

ETA1617

Boost for TFT bias and LED driver

Non-Sync

2.7

Vin

0.2

800K

200

SOT23-6

High Output Voltage,TFT bias

高输出电压，供TFT偏压，LED背光

ETA1621

22V/2A Non-Sync.Boost

Non-Sync

2.5

Vin

2.8

0.6

250

SOT23-6

High Output Voltage

高输出电压，通用升压

ETA1625

22V/2A Non-Sync.Boost

Non-Sync

2.5

Vin

2.8

0.6

550K

250

SOT23-6

High Output Voltage

高输出电压，通用升压

ETA1627

Boost for TF]

Non-Sync

2.7

Vin

800K

300

SOT23-6

High Output Voltage for LED Series

异步多串LED背光驱动，调光精度0.1%

ETA1637

30V/50mA LED Driver

Sync.True-shutoff

2.7

Vin

1.5

600K

300

SOT23-6

Sync.2x8 LED drivers with 0.1%dimming duty

同步真关断背光LED驱动，调光精度0.1%

ETA1638

30V/50mA LED Driver

Sync.True-shutof

2.7

Vin

1.5

600K

300

DFN2x2-6

Sync.2x8 LED drivers with 0.1%dimming duty

同步真关断背光LED驱动，调光精度0.1%

降压稳压器
Part No	Descriptior	Architecture	Vin Min(V)	Vin MaxM)	Vout MinM	Max Duty(%)	lout Max(A)	Vfb(V	Switching Frequency(HZ	lq(uA)	Package	Comment	备注
ETA1459	I2C/18V/2.5A Sync.Buck	2C,Sync	4.2	18	0.696-1.2	90	2.5	0.696-1.2	500K	750	ESOPg	I2C Vout programmable,PFM/PWM	智能机顶盒主控供电，扬智方案
ETA1466	18V/2A Sync.Buck	Sync.COI	4.5	18	0.806	97		0.806	700K	177	SOT23-6	Ultra-fast response	快速响应，COT控制，兼容MP1470
ETA1467	18V/3A Sync.Buck	Sync,COT	4.5	18	0.8	97		0.8	700K	177	SOT23-6	Ultra-fast response	快速响应，COT控制，兼容MP1471
ETA1468	24V/2A Sync.Buck	Sync.COT	3.5	24	0.8	92		0.8	1M	10000	SOT23-6	Forced PWM Mode	定频驱动，通用降压，COT控制
ETA1469	8V/2A Sync.Buck	Sync.COT	4	18	0.6	80	2	0.6	1M	10000	SOT23-6	Vin OVP at 19V,Forced PWM Mode	定频驱动，通用降压，COT控制
ETA1470	18V/2A Sync.Buck	Sync	4.5	18	0.8	93	2	0.8	500K	640	FCTSOT23-6	Vin OVP at 19V,PFM/PWM	轻载高效，通用降压
ETA1471	18V/3A Sync.Buck	Sync	4.2	18	0.8	99	3	0.8	500K	700	FCTSOT23- 6/ESOP8	PFM/PWM	轻载高效，通用降压，兼容TPS563201
ETA1476	28V/2A Sync.Buck	Sync	4.5	28	0.6	93	2	0.6	500K	640	FCTSOT23-6	PFM/PWM	轻载高效，通用降压，兼容TPS54202
ETA1477	24V/2A Sync.Buck	Sync.COT	4.5	24	0.768	90		0.768	600K	177	SOT23-6	PFM/PWM	轻载高效，通用降压，兼容TPS562200/TPS62201
ETA1478	18V/2A Sync.Buck	Sync	4.5	18	0.8	93		0.8	500K	640	SOT23-6	PFM/PWM	轻载高效，通用降压
ETA1483	8V/2A Sync.Buck	Sync.Ext comp	3.6	18	0.92;	91		0.923	340K	1000	SOP8	Vin OVP at 20V,PFM/PWM	轻载高效，通用降压
ETA1485	18V/3A Sync.Buck	Sync.Ext comp	3.6	18	0.923	91	3	0.923	340K	1000	ESOP8	Vin OVP at 20V,PFM/PWM	轻载高效，通用降压
ETA1486	18V/4A Sync.Buck	Sync.Ext comp	4.2	18	0.923	91		0.923	340K	1600	ESOpc	18V 4A,external comp.	4.2-18V宽输入范围，4A输出电流
ETA1650	17V/2A Sync.Buck	Sync.COT	4.2	17	0.8	87		0.8	650K	10000	SOT563	Vin OVP at 18.4V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1651	17V/2A Sync.Buck	Sync,COT	4.2	17	0.6	87	2	0.6	1M	10000	SOT563	Vin OVP at 18.4V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1652	18V/2A Sync.Buck	Sync.COT	4.5	18	0.806	87		0.806	600K	177	SOT563	Vin OVP at 19V,PFM/PWM	快速响应，COT控制，兼容MP1652/MP1657
ETA1653	18V/3A Sync.Buck	Sync,COT	4.5	18	0.806	87		0.806	700K	177	SOT563	Vin OVP at 19V,PFM/PWM	快速响应，COT控制，兼容MP1653/MP1658
ETA1654	18V/4A Sync.Buck	Sync,COT	4.5	18	0.805	97	4	080k	600K	230	SOT563	Vin OVP at 19V PEM/PWN	快速响应，COT控制，兼容MP1654
ETA1655	18V/4.5A Sync.Buck	Sync.COj	4.5	18	0.805	97	4.5	0.805	600K	230	FCDFN2x2-6	Vin OVP at 19V,PFM/PWM	快速响应，COT控制，兼容MP1655
ETA1656	18V/5A Sync.Buck	Sync.COI	4.5	18	0.6	97		0.6	600K	230	DFN2x2-6	Vin OVP at 19V,PFM/PWM	快速响应，COT控制
ETA1657	18V/5A Sync.Buck	Sync.COI	4.5	18	0.805	97		0.805	600K	230	DFN2x2-6	Vin OVP at 19V,PFM/PWM	快速响应，COT控制
ETA1659	18V/5A Sync.Buck	Sync Con	4.5	18	0.6	97		0.6	600K	6000	DFN2x2-6	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1660	18V/5A Sync.Buck	Sync,COT	4.5	18	0.805	97		0.805	600K	6000	DFN2x2-6	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1661	18V/4A Sync.Buck	Sync.COT	4.5	18	0.6	97		0.6	600K	230	SOT563	Vin OVP at 19V,PFM/PWM	快速响应，COT控制
ETA1662	18V/4A Sync.Buck	Sync,COT	4.5	18	0.805	97	4	0.805	600K	6000	SOT563	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1663	18V/4A Sync.Buch	Sync.COT	4.5	18	0.6	97		0.6	600K	6000	SOT563	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1664	18V/4.5A Sync.Buck	Sync,COT	4.5	18	0.6	97	4.5	0.6	600K	230	FCDFN2x2-6	Vin OVP at 19V,PFM/PWM	快速响应，COT控制
ETA1665	18V/4.5A Sync.Buck	Sync,COT	4.5	18	0.805	97	4.5	0.805	600K	6000	FCDFN2x2-6	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1666	18V/4.5A Sync.Buck	Sync.COJ	4.5	18	0.6	97	4.5	0.6	600K	6000	FCDFN2x2-6	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1667	17V/3A Sync.Buck	Sync.COI	4.2	17	0.6	87		0.6	1M	3800	SOT563	Vin OVP at 18.4V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA1753	18V/3A Sync.Buck	Sync.COT	4.5	18	0.806	87		0.806	1M	177	SOT563	Vin OVP at 19V,PFM/PWM	快速响应，COT控制，兼容CD1053
ETA1801	100N/0.6A Sync.Bucl	Sync.COT	7	100	1.2	99	0.6	1.2	0.2-1M	280	ESOP8	PFM/PWM,ultra-fast response	快速响应，COT控制，频率可调，兼容SY8501
ETA1802	100V/0.6A Sync.Buck	Sync,COT		100	1.2	99	0.6	1.2	0.2-1M	280	ESOP8	PFM/PWM,ultra-fast response	快速响应，COT控制，频率可调
ETA1805	100V/1.5A Sync.Buck	Sync.COT		100	1.2	99	1.5	1.2	0.2-1M	280	ESOP8	PFM/PWM,ultra-fast response	快速响应，COT控制，频率可调
ETA2236	17V/6A Sync.Buck	Sync,COT	4.5	17	0.6	93	6	0.6	550K	230	FCTSOT23-8 /DFN3x3-10	PFM/PWM,auto switching	轻载高效，COT控制，兼容MP2236
ETA2807	42V/3A Sync.Buck	Sync	4.6	42	0.8	100	3	0.8	250K	460	FCTSOT23-6	Vin OVP at 43V,PFM/PWM	车充应用，线补
ETA2808	42V/3A Sync.Buck	Sync.	4.6	42	0.8	100		0.8	0.12-1.1M	500	ESOP8	Vin OVP at 43V,PFM/PWM	车充应用，线补，频率可调
ETA2821	38V/1.5A Non-Sync.Buck	Non-Sync		38	0.8	90	1.5	0.8	650K	600	SOT23-6	Vin OVP at 38V,PFM/PWM	38V过压保护，高耐压，兼容MP2451
ETA2822	36V/3.1A Non-Sync.Buck	Non-Sync	4	36	0.8	90	3.1	0.8	0.1-1M	850	ESOP8	Vin OVP at 37.5V,for Car Charger	车充应用，线补，频率可调
ETA2823	28V/2A Sync.Buck	Sync.	4.2	28	0.8	99	2	0.8	500K	700	ESOP8	PFM/PWM	轻载高效，通用降压

降压稳压器
Part No	Descriptior	Architecture	Vin MinW	Vin MaxM]	Vout MinM)	Max Duty(%)	lout Max(A)	yfb(V	Switching Frequency(HZ)	lq(uA	Package	Comment	备注
ETA2831	36V/3.5A Non-Sync.Buck	Non-Sync		36	0.8	90	3.5	0.8	0.1-1M	850	QFN3x3-16	Vin OVP at 37.5V,for Car Charger	车充应用，线补，频率可调，双口输出
ETA2838	28V/2.5A Car Charger w.QC	Non-Sync QC2.0/PE+	4.5	28	5	99	2.5	NA	Adjustable	500	ESOP8	36V Standoff,QC2.0&PE+	36V耐压，自带QC2.0和PE+快充协议
ETA2841	38V/0.6A Non-Sync.Buck	Non-Sync.	4	38	0.8	90	0.6	0.8	650K	600	SOT23-6	Vin OVP at 38V,PFM/PWM	38V过压保护，高耐压
ETA2842	38V/1A Non-Sync.Buck	Non-Sync.		38	0.8	90		0.8	650K	600	SOT23-6	Vin OVP at 38V,PFM/PWM	38V过压保护，高耐压
ETA2843	36V/0.4A Non-Sync.Buck	Non-Sync.	4	36	0.8	90	0.4	0.8	750K	850	SOT23-6	Vin OVP at 38V,PFM/PWM	38V过压保护，高耐压
ETA2845	38V/0.4A Sync.Buck	Sync		38	0.8	99	0.4	0.8	700K	420	SOT23-6	Vin OVP at 37.5V,PFM/PWM	37.5V过压保护，高耐压
ETA2847	30V/2A Sync.Buck	Sync Cor		30	0.596	100		0.596	500K	320	SOT23-6	Vin OVP at 32V,PFM/PWM	32V过压保护，高耐压，兼容TPS54202H
ETA2848	38V/0.4A Sync.Buck	Sync	5	38	0.8	99	0.4	0.8	700K	420	SOT23-6	Vin OVP at 37.5V,PFM/PWM	37.5V过压保护高耐压
ETA2892	40V/3A Sync.Buck	Sync	3.6	40	1	99	3		0.13-1.1M	10000	ESOP8	Vin OVP at 40V,Forced PWM Mode	40V过压保护，高耐压，频率可调
ETA2893	40V/3A Sync.Buck	Sync.	3.6	40		99			0.13-1.1M	9	ESOPs	Vin OVP at 40V,PFM/PWM	9uA超低功耗，40V过压保护，高耐压，频率可调
ETA2894	40V/3A Sync.Buck	Sync	3.6	40		99	3		0.13-11M	9	QFN3x4-24	Vin OVP at 40V,PFM/PWM	9uA超低功耗，40V过压保护，高耐压，频率可调
ETA3406	6V/1.2A Sync.Buck	Sync.	2.6	6	0.6	100	1.2	0.6	1.5M	38	SOT23-5	PF/PWM auto switching	轻载高效，通用降压
ETA3408	6V/1A Sync.Buck	Sync	2.6	6	0.6	100		0.6	1.5M	40	SOT23-5	PFM/PWM auto switching	轻载高效，兼容日系脚位
ETA3409	7.3V/3A Sync.Buck	Sync	2.4	7.3	0.6	100		0.6	1M	42	SOT23-5	Fast startup.PFM/PWM	轻载高效，快速启动，兼容TLV62569
ETA3410	5.5V/2A Sync.Buck	Sync	2.6	5.5	0.6	100	2	0.6	3M	30	DFN2x2-8	PWM/PFM configurable	快速启动，兼容NCP6324 /TPS62065
ETA3411	5.5V/2A Sync.Buck	Sync	2.1	5.5	0.6	100	2	0.6-3.4	3M	30	DFN1.5x1-6 DFN1.6x1.6-6 DFN2x2-8	Fast startup,PFM/PWM	快速启动，NBIOT应用，兼容LM3241
ETA3412	Dual 6V/1.2A Sync.Buck	Sync	2.6	6	0.6	100	1.2	0.6	1.5M	38	SOP8	Dual outputs.PFM/PWN	双路输出，轻载高效，通用降压
ETA3413	7V/2.5A Sync.Buck	Sync	2.6		0.6	100	2.5	0.6	3M	8000	SOT23-5	Forced PWM Mode	定频驱动，通用降压
ETA3414	7V/1A Sync.Buck	Sync	2.6		0.6	100	1	0.6	3M	8000	SOT23-5	Forced PWM Mode	定频驱动，通用降压
ETA3415	7V/1A Sync.Buck	Sync.	2.6		0.6	100		0.6	3M	20	SOT563	PF/PWM auto switching	轻载高效，通用降压兼容MP1601/TLV62568
ETA3416	7V/1.5A Sync.Buck	Sync	2.6		0.6	100	1.5	0.6	3M	20	SOT23-5	PFM/PWM auto switching	轻载高效，通用降压
ETA3417	7V/2.5A Sync.Buck	Sync	2.6		0.6	100	2.5	0.6	3M	32	SOT23-5	PF/PWM auto switching	轻载高效，内部补偿，兼容SY8089/TLV62569
ETA3418	7V/2.5A Sync.Buck	Sync.	2.6		0.6	100	2.5	0.6	3M	8000	SOT23-5	Forced PWM Mode	定频驱动，通用降压
ETA3423	6.5V/1A Sync.Buck	Sync	2.6	6.5	0.6	100		0.6	3M	6000	SOT563	Forced PWM Mode	定频驱动，通用降压，兼容TLV62568A
ETA3424	7V/1.5A Sync.Buck	Sync	2.6		1.2	100	1.5	NA	3M	6000	SOT23-5	Forced PWM Mode	定频驱动，固定输出1.2V/2.5V/3.3V
ETA3425	7V/0.6A Sync.Buck	Sync	2.6		1.11	100	0.6	1.11	1.4M	1.2	SOT23-5/DFN2x2-6	UItra low la.for wearable/NBIO	快速响应，超低功耗，NBIOT
ETA3426	7V/1.2A Sync,Buck	Sync.	2.6		1.129	100	1.2	1.129	1.4M		SOT23-5/DFN2x2-6	UItra low lq,for wearable/NBIOT	快速响应，超低功耗，NBIOT
ETA3427	7V/1.2A Sync,Buck	Sync	2.6		0.788	100	1.2	0.788	1.4M	2	SOT23-5/DFN2x2-6	Ultra low lq,for wearable/NBIOT	快速响应，超低功耗，NBIOT
ETA3446	55V/3A Sync.Buck	Sync.COI	2.5	5.5	0.6	100		0.6	2M	50	SOT23-5	PFM/PWM auto switching	轻载高效，通用降压
ETA3448	5.5V/3A Sync.Buck	Sync.COI	2.5	5.5	0.6	100	3	0.6	2M	8000	SOT23-5	Forced PWM Mode	定频驱动，快速响应，COT控制
ETA3451	5.5V/2A Sync.Buck	Sync.COJ	2.6	5.5	0.45	100		0.45	1.5M	50	DFN2x2-8	Vin OVP at 6.25V,Fast response	快速响应，COT控制，兼容TLV62084/RT571
ETA3452	5.5V/3A Sync.Buck	Sync.COI	2.6	5.5	0.45	100		0.45	1.5M	50	SOT23-6	Vin OVP at 6.25V,Fast response	快速响应，COT控制
ETA3453	5.5V/3A Sync.Buck	Sync.COT	1.75	5.5	0.45	100	3	0.45	1.5M	50	DFN2x2-8/SOT23- 6	Vin OVP at 6.15V,Fast response	快速响应，COT控制，宽输入范围
ETA3456	5.5V/3A Sync.Buck	Sync.COI	2.5	5.5	0.6	100	3	0.6	2M	50	SOT563	PFM/PWM auto switching	轻载高效，通用降压，兼容MP1603/MP2523
ETA3457	5.5V/2.5A Sync.Buck	Sync,COr	2.5	5.5	0.6	100	2.5	0.6	2M	50	QFN-12	PFM/PWM auto switching	轻载高效，电感内置
ETA3458	5.5V/3A Sync.Buck	Sync.COT	2.5	5.5	0.6	100	3	0.6	2M	6000	SOT563	Forced PWM Mode	定频驱动，快速响应，COT控制
ETA3481	5.5V/2A Sync.Buck	Sync	3.6	5.5	0.8	100		0.8	1.4M	450	SOP8	PFM/PWM auto switching	轻载高效，通用降压
ETA3485	7V/1.5A Sync.Buck	Sync	2.6		0.6	100	1.5	0.6	2M	20	SOT23-5	PFM/PWM auto switching	轻载高效，RF射频应用，兼容TLV62568/SY8088
ETA3486	6V/1A Sync.Buck	Sync.	2.6	6	0.6	100		0.6	1.5M	40	SOT23-5	PFM/PWM auto switching	轻载高效，通用降压
ETA3496	7.2V/1.2A Sync.Buck	Sync	2.5	7.2	0.6	99	1.2	0.6	1.2M	34	SOT23-5	PFM/PWM auto switching,OVP for input surge轻载高效，12V耐压，防输入浪涌

降压稳压器
Part No	Description	Architecture	Vin MinV	Vin Max(V	Vout Min(V)	Max Duty(%	lout Maxa	Wfb(V	Switching Frequency(HZ)	lq(uA)	Package	Commen	备注
ETA3499	7.3V/3A Sync.Buck	Sync	2.4	7.3	0.6	99	3	0.6	1M	42	SOT23-6	PFM/PWM auto switching,OVP for input surge	轻载高效，9V耐压，防输入浪涌，兼容SY8032
ETA3512	6V/3A Sync.Buck	Syne Co]	2.5	6	0.6	100	3	0.6	2M	50	SOT563	PEM/PWM auto switching	轻载高效，通用降压，兼容SY8892
ETA3514	6V/3A Sync.Buck	Sync.COT	2.5		0.6	100	3	0.6	2M	50	DFN2x2-8	PFM/PWM auto switching	轻载高效，通用降压，兼容RT5797A
ETA3515	6V/3A Sync.Buck	Sync.COI	2.5	6	0.6	100		0.6	2M	50	SOT563	PFM/PWM auto switching	轻载高效，通用降压，兼容MP1605/TLV62569
ETA3517	6V/3A Sync.Buck	Sync.Co	2.5	6	0.6	100	3	0.6	2M	50	SOT563	Forced PWM Mode	定频驱动，通用降压，兼容SY8892E	机
ETA3521	6V/4A Sync.Buck	Sync.COI	2.5	6	0.6	100		0.6	2M	50	SOT563	PFM/PWM auto switching	轻载高效，通用降压
ETA3525	6V/3A Sync.Buck	Sync Coi	2.5		0.6	100		0.6	2M	50	SOT563	Forced PWM Mode	定频驱动，通用降压，兼容MP1605C
ETA3526	6V/2A Sync.Buck	Sync.COI	2.5	6	0.6	100	2	0.6	2M	50	SOT563	PFM/PWM auto switching	轻载高效，通用降压，兼容MP1602
ETA3527	6V/2A Sync.Buc	Sync.COT	2.5	6	0.6	100	2	0.6	2M	5500	SOT563	Forced PWM Mode	定频驱动，通用降压
ETA3555	I2C/5.5V/5A Sync.Buck	I2C,Sync.COT	2.5	5.5	0.6	100	5	I2C	2M	55	CSP-20	I²C Vout Setting Fast response Addr=COH	智能手机/平板主控供电
ETA355C	I2C/5.5V/5A Sync.Buck	I2C,Sync.COT	2.5	5.5	0.6	100	5	l2C	2M	55	CSP-20	2C Vout Setting Fast response.Addr=COH	平板主控供电
ETA355D	I2C/5.5V/5A Sync.Buck I	2C,Sync.COT	2.5	5.5	0.6	100	5	I2C	2M	55	CSP-20	2C Vout Setting Fast response,Addr=COH	展讯4G平台定制，兼容FAN53555
ETA355E	I2C/5.5V/5A Sync.Buck	I2C,Sync.COT	2.5	5.5	0.6	100	5	I2C	2M	55	CSP-20	I2C Vout Setting Fast response.Addr=COH	智能手机/平板主控供电
ETA3560	6V/1A Sync.Buck	Sync	2.6	6	0.6	100	1	0.6	1.5M	40	DFN2x2-6	PFM/PWM auto switching	轻载高效，MTK穿戴方案，展讯手机方案兼容TPS62560
ETA3655	5.5V/5A Sync.Buck w.ADI	ADI.Sync.COT	2.5	5.5	0.6	100	5	ADI	2M	70	CSP-20	ADI Vout Setting,Fast response	智能手机供电，展讯方案，ADI快速调压
ETA3707	360nA lq,5.5V/1A Sync.Buck	Sync.COI	2.1	5.5	1.2	100		NA	1.2M	0.36	CSP-8/DFN2x2-8	360nA ulra-low lg,Programmable output voltage	轻载高效，超低功耗，兼容RT5707
ETA3707A	360nA lq,5.5V/0.5A Sync.Buc	Sync,COT	2.1	5.5	0.7	100	0.5	NA	1.2M	0.36	CSP-8/DFN2x2-8	360nA ultra-low lq,Programmable output voltage	轻载高效，超低功耗，兼容RT5707A
ETA4000	12V/400mA Buck w.charge pump	Linear	4.4	16	1.1	NA	0.4	1.1	820K	155	SOP8	12V Buck with charge pump,high efficiency	采用高效的电容电荷转换，无电感
ETA8010	6V/1A Sync.Buck	Sync	2.6		0.6	100		0.6	1.5M	40	DFN2x2-6	PFM/PWM auto switching	轻载高效，兼容RT8010
ETA8015	5.5V/3A Sync.Buck	Sync	3.6	5.5	0.8	100		0.8	1.8M	420	DFN3x3-10	External compensation	高频驱动，大电流输出
ETA8103	18V/3A Sync.Buch	Sync.COT	4	18	0.6	80	3	0.6	1M	7000	SOT23-6	Forced PWM Mode	定频驱动，快速响应，COT控制，兼容SY8113C
ETA8110	24V/2A Sync.Buck	Sync,COn	3.5	24	0.6	92		0.6	1M	10000	SOT23-6	Forced PWM Mode	定频驱动，快速响应，COT控制
ETA8111	24V/2A Sync.Buck	Sync.COT	3.5	24	0.6	92		0.6	1.4M	10000	SOT23-6	Forced PWM Mode	定频驱动，快速响应，COT控制
ETA8113	18V/3A Sync.Buck	Sync.COI	4.5	18	0.603	97	3	0.603	500K	177	SOT23.6	PE/PWM auto switching	轻载高效，快速响应，COT控制，兼容SY8113
ETA8120	18V/2A Sync.Buck	Sync.CoI	4.5	18	0.6	97		0.6	600K	177	SOT23-6	PFM/PWM auto switching	轻载高效，兼容SY8120
ETA8121	28V/2A Sync.Buch	Sync	4.2	28	0.8	99		0.8	1M	750	SOT23-6	Forced PWM Mode	定频驱动，通用降压，兼容SY8121
ETA8123	18V/3A Sync.Buck	Sync.COT	4	18	0.6	80		0.6	600K	7000	SOT23-6	Forced PWM Mode	定频驱动，快速响应，COT控制
ETA8156	17V/6A Sync.Buck	Sync.COT	4.5	17	0.6	97	6	0.6	550K	230	FCTSOT23-6	PFM/PWM auto switching	轻载高效，兼容SY8156
ETA8210	18V/2A Sync.Buck	Sync.COI	4	18	0.6	80		0.6	1M	10000	SOT23-6	Vin OVP at 19V,Forced PWM Mode	定频驱动，快速响应，COT控制
ETA8220	18V/2A Sync.Buck	Sync.COI	4.5	18	0.6	97		0.6	700K	177	SOT23-E	PE/PWM auto switching	轻载高效，快速响应，COT控制，兼容SY8120
ETA8222	18V/2A Sync.Buck	Sync.COT	4.5	18	0.6	99	2	0.6	1M	210	SOT23-6	PFM/PWM auto switching	轻载高效，快速响应，COT控制
ETA8291	Dual 24V/2A Sync.Buck	Sync.COI	3.5	24	0.6	90	2	0.6	600K	210	DFN3x3-10	PEM/PWM auto switchinc	双路输出，轻载高效
ETA8322	26V/2A Sync.Buck	Sync.COT	4.5	26	0.6	99		0.6	1M	210	SOT23-6	PFM/PWM auto switching	轻载高效，快速响应，COT控制
ETA9338	3 channels 5.5V/1.5A Sync.Buck	Sync	2.6	5.5	0.6	99	1.5	0.6	1.5M	40	DFN3x3-12	3 channels output,meet small PCB demand	高集成度，3路输出，机顶盒，摄像机等
ETA9351	3 channels 5.5V/3.5A Sync.Buck	Sync.COT	2.6	5.5	0.45	99	3.5	0.45	1.5M	50	QFN4x4-24	3 channels output,meet small PCB demand	高集成度，大功率，3路输出，机顶盒，摄像

锂电池充电器

Part No

Description

Architecture

Vin Min(V)

/in Max(V

Vin
StandoffV

Final Vbat(V

PP Rdson(mΩ

Charge
MaXlA

switching
FrequencylHz

OTG

Packag

commen

备注

ETA4016

120mA Linear 4.2V Charge

Linear

4.25

4.2

0.12

DFN2x2-8

4.2V VBAT,120mA linear charger

线性充电，截止电流低至1mA,兼容BQ25101

ETA4036

1.2A Linear 3.65V Charger

Linear

4.25

3.65

1.2

ESOP8

3.65V VBAT,1.2A linear charger

磷酸铁锂电池

ETA4040

1A Linear 4.2V Charger

Linear

4.5

6.5

4.2

DFN2x2-10

4.2V VBAT,1A linear charger

线性充电双灯指示， JE A

ETA4041

1A Linear 4,2V Charge

Linear

4.25

4.2

SOT23-5

4.2V VBAT,1A linear charger

线性充电，单灯指示，温度反折

ETA4042

1A Linear 4.2V Chargei

Linear

4.25

4.2

DFN3x3-10

4.2V VBAT,1A linear charger

线性充电双灯指示，NTC监控，温度反折，兼容
MP2602

ETA4043

1A Linear 4,2V Charge

Linear

4.25

4.2

DFN2x3-8

4.2V VBAT,1A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA4044

0.75A Linear 4.2V Charger

Linear

4.25

4.2

0.75

SOT23-5

4.2V VBAT,0.75A linear charger

通用线性充电，单灯指示，20%涓流

ETA4045

1A Linear 4.2V Charger

Linear

4.25

4.2

ESOP8

4.2V VBAT,1A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA4046

1.2A Linear 4.2V Charge

Linear

4.25

4.2

1.2

ESOP8/DFN2x2-
8/DFN2x3-8/SOT23-6

4.2V VBAT,1.2A linear charger

线性充电双灯指示，NTC监控，温度反折，20%涓流和
截止电流

ETA4047

1A Linear 4.2V Charger

Linear

4.25

4.2

DFN3x3-10

4.2V VBAT,1A linear charge

线性充电双灯指示， N T C 监控，振荡周期设置，兼
容 M P 2 6 0 5

ETA4048

1A Linear 4.2V Charger

Linear

4.25

4.2

DFN3x3-10

4.2V VBAT,1A linear charger

线性充电，双灯指示，NTC监控

ETA4049

1A Linear 4,2V Charger

Linear

4.25

4.2

DFN3x3-10

4.2V VBAT,1A linear charger

线性充电，双灯指示，NTC监控，振荡周期设置

ETA4050

1A Linear 4.35V Charger

Linear

4.5

6.5

4.35

DFN2x2-10

4.35V VBAT,1A linear charger

线性充电，双灯指示，JEITA功能

ETA4051

1A Linear 4.35V Charger

Linear

4.25

4.35

SOT23-5

4.35V VBAT,1A linear charger

线性充电，单灯指示，温度反折

ETA4052

1.2A Linear 4.2V Charge

Linear

4.25

4.2

1.2

DFN3x3-10

4.2V VBAT,1.2A linear charger

线性充电，单灯指示，NTC监控

ETA4054

1A Linear 4.2V Charger

Linear

4.25

4.2

SOT23-5

4.2V VBAT,1A linear charger

通用线性充电，单灯指示，温度反折，兼容LT4054

ETA40543

1.2A Linear 4.35V Charger

Linear

4.25

4.35

1.2

ESOP8/SOT23-6

4.35V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA4056

1.2A Linear 4.2V Charger

Linear

4.25

4.2

1.2

ESOP8/DFN2x2-
8/DFN2x3-8/SOT23-6

4.2V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA40561

1.2A Linear 4.2V Charge

Linear

4.25

4.2

1.2

ESOP8

4.2V VBAT,1.2A linear charger,10.6V
OVP

线性充电，双灯指示，NTC监控，温度反折

ETA40563

1.2A Linear 4.35V Charger

Linear

4.45

4.35

1.2

DFN2x2-8

4.35V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA4058

2 in 1,1.2A Linear Charger+300mA LDO

Linear

4.45

4.35

1.2

DFN2x3-8

1.2A linear charger+300mA LDO

线性充电+LDO,二合一

ETA4060

1A Linear 4.4V Charge

Linear

4.5

6.4

4.4

DFN2x2-10

4.4V VBAT,1A linear charger

线性充电，双灯指示，JEITA功能

ETA4084

0.75A Linear 8.4V Charger

Linear

8.5

8.4

0.75

SOT23-6

8.4V VBAT,0.75A linear charger

双节通用线性充电，单灯指示，温度反折

ETA4085

1A Linear 4.2V Charger

Linear

4.35

6.5

4.2

DFN3x3-10

4.2V VBAT,1A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA4116

120mA Linear 4.35V Charger

Linear

4.25

4.35

0.12

DFN2x2-8

4.35V VBAT,120mA linear charger

线性充电，截止电流低至1mA

ETA4140

1A Linear 4.2V Charger,low input supply current

Linear

4.5

6.5

4.2

DFN2x2-10

4.2V VBAT,1A linear charger

线性充电双灯指示，JEITA功能，输入低功耗，兼容
SN2040

ETA4098

500mA Charger w.DPPM

Linear

3.73

18.5

4.2/4.35

100

0.5

FCQFN1.75x1.75-9
CSP-9

DPPM,4.2/4.35V linear charger

路径管理，蓝牙耳机

ETA4255

1.2A Linear 4.2V Charger

Linear

4.25

4.2

1.2

ESOP8

4.2V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，温度反折

ETA4256

1.2A Linear 4,2V Charge

Linear

4.25

4.2

1.2

DFN3x3-10

4.2V VBAT,1.2A linear charger

线性充电
MP2602

双灯指示，NTC监控，温度反折，兼容

ETA42564

1.2A Linear 4.4V Charger

Linear

4.25

4.4

1.2

DFN3x3-10

4.4V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，温度反折

锂电池充电器

Part Nc

Description

Architecture

in Min(V

Vin Max(V

Vin
Standoff(V

Final Vbat(V)

PP Rdson(mQ

Charn

Switching

OTG

Packag

Comment

备注

ETA4257

1.2A Linear 4.2V Charger

Linear

4.25

4.2

1.2

DFN3x3-10

4.2V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，振荡周期设置，兼
容MP2605

ETA4258

1.2A Linear 4.2V Charge

Linear

4.25

4.2

1.2

DFN3x3-10

4.2V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，OVP可调

ETA4259

1.2A Linear 4.2V Charger

Linear

4.25

4.2

1.2

DFN3x3-10

4.2V VBAT,1.2A linear charger

线性充电，双灯指示，NTC监控，振荡周期设置

ETA4662

500mA Charger w.DPPM,I2C Control

Linear

3.73

5.85

I2C control

170

0.5

DPPM.I2C control.500mA linear
charger

路径管理，I2C,蓝牙耳机，兼容MP2662

TA6002

2.5A Charger w.DPPM

Sync.Buck+NVDC

4.4

5.5

4.2

2.5

ESOP8

Input DPM&OVP,Vsys 2.5A output

输入功率自适应

ETA6003

2.5A Charger w.DPPM

Sync.Buck+NVDC

4.4

5.5

4.2

2.5

QFN3x3-16

Input DPM&OVP,Vsys 2.5A output

输入功率自适应，过压保护，系统供电2.5A

ETA6005

2.5A Charger w.DPPM

Sync.Buck+NVDC

4.4

5.5

4.35

2.5

QFN3x3-16

Input DPM&OVP,Vsys 2.5A output

输入功率自适应，过压保护，系统供电2.5A

ETA6017

1.5V/2A Buck&5V Linear Charger

Sync.Buck+Linear

3.85

5.5

4.2/4.35

QFN3x3-16

1.5V dry cell compatible Li+battery

兼容5号干电池的可充电锂电池

ETA6071

2.5A Boost Charger w.2.4A OTG

Sync.Boost+OTG

2.7

8.4

2.5

2.4A

QFN3x3-20

Boost charger for dual batteries

5V升2节电池充电，支持电池降压到输入端

ETA6094

2A Charger w.1.5A OTG

Sync.Buck+OTG

4.5

5.5

4.2

1.2M

1.5A

DFN2x3-8/ESOP8

Input Auto-Detect,general purpose

输入自动探测，通用于便携锂电系统

ETA6095

2.5A Charger w.1.5A OTG

Sync.Buck+OTG

4.5

5.5

4.2

2.5

1.2M

1.5A

DFN2x3-8

Charger/OTG manually controlled

充电/OTG模式由引脚控制，手机和平板电脑应用

ETA6096

32V Input standoff,2.5A Charger

Sync.Buck

4.5

5.5

4.2

2.5

DFN3x3-10

2.5A switch charger,32V input
standoft voltage

高耐压，纯硬件开关充

ETA6097

2.5A Switch Charger,luA ultra low
VBAT standby current

Sync.Buck

4.5

5.5

6.5

4.2

2.5

DFN2x3-8

2.5A switch charger,luA ultra low
VBAT standby current

高耐压，纯硬件开关充

ETA6098

32V Input standoff,2.5A Charger,1uA
ultra low VBAT standby current

Sync.Buck

4.5

5.5

4.2

2.5

DFN3x3-10

2.5A switch charger,32V input
standoff,luA ultra low VBAT standby

高耐压，纯硬件开关充，电子烟

ETA6102

2.5A Charger w.DPPM

Sync.Buck+NVDC

4.4

5.5

4.35

2.5

ESOP8

Input DPM%OVP,Vsys 2.5A output

输入功率自适应，过压保护，系统供电2.5A

ETA6195

2.5A Charger w.1.5A OTG

Sync.Buck+OTG

4.5

5.5

4.35

2.5

1.2M

1.5A

DFN2x3-8

Charger/OTG manually controlled

充电/OTG模式由引脚控制，手机和平板电脑应用

ETA6196

32V Input standoff,2.5A Charger

Sync.Buck

4.5

5.5

4.35

2.5

DFN3x3-10

2.5A switch charger,32V input
standoff voltage

高耐压，纯硬件开关充

ETA6198

32V Input standoff,2.5A Charger,luA
ultra low VBAT standby current

Sync.Buck

4.5

5.5

4.35

2.5

DFN3x3-10

2.5A switch charger,32V input
standoff,luA ultra low VBAT standby

高耐压，纯硬件开关充，电子烟

ETA6200

1.5V/3V Buck&5V Linear Charger

Sync.Buck+Linear

3.2

4.16/4.31

2.7M

DFN3x3-10

1 or 2 dry cells compatible Li+battery

兼容1或2节5号干电池的可充电锂电池

ETA6298

32V Input standoff,2.5A Charger,luA
ultra low VBAT standby current

Sync.Buck

4.5

5.5

4.4

2.5

DFN3x3-10

2.5A switch charger,32V input
standoff,1uA ultra low VBAT standby

高耐压，纯硬件开关充，电子烟

ETA6911

20V Input standoff,4A Switch Charger

Sync.Buck

4.6

4.2/4.35

QFNFC1.7x2-20/QFN4×4-24

4A switch charger,input DPM

输入功率自适应，过压保护，4A纯硬件开关充

ETA6937

3A Charger w.1A OTG,I2C Control

Sync.Buck+OTG

3.8

3.5-4.44

1.3M

CSP-20

Charger/OTG manually controlled

充电/OTG模式由引脚控制，手机和平板电脑应用，
兼容BQ24157/BQ24158

ETA6953

3A Charger w.1.2A OTG,I2C Control

Sync.Buck+OTG+NVDC

3.9

13.5

3.856-4.624

1.5M

1.2A

QFN4x4-24

Charger/OTG.Vfloat=3856-4624V

充电/OTG模式由引脚控制，手机和平板电脑应用，
兼容BQ25601

ETA6954

3A Charger w.1.2A OTG

Sync.Buck+OTG+NVDO

3.9

13.5

4.2/4.35/4.4

1.5M

1.2A

QFN4x4-24

Charger/OTG,Vfloat=4.2/4.35/4.4V

充电/OTG模式由引脚控制，手机和平板电脑应用

ETA6963

3A Charger w.1.2A OTG,I2C Control

Sync.Buck+OTG+NVDC

3.9

13.5

3.848-4.616

1.5M

1.2A

QFN4x4-24

Charger/OTG,Vfloat=3.848-4.616V

充电/OTG模式由引脚控制，D+/D-,兼容BQ25601D

ETA6964

3A Charger w.1.2A OTG

Sync.Buck+OTG+NVDO

3.9

13.5

4.2/4.35/4.4

1.5M

1.2A

QFN4x4-24

Charger/OTG,Vfloat=4.2/4.35/4.4V

充电/OTG模式由引脚控制，兼容BQ25606

ETA6965

3A Charger w.1.2A OTG,I2C Control

Sync.Buck+OTG+NVDC

3.9

13.5

3.848-4.616

1.5M

1.2A

QFN4x4-24

Charger/OTG,Vfloat=3.848-4.616V

充电/OTG模式由引脚控制，D+/D-

移动电源IC

Part Nc

Description

ndicato

Boos

Charge

Toleration(V)

Package

Comment

备注

ETA6085

2 in 1,work with MCU

Chrg LED,MCU defined

5V/2.5A Sync

4.2V/3A adj

QFN3x3-20

PowerSOC+,2 in 1,work with MCU

移动电源，苹果、安卓背夹等

ETA6093

3 in 1,Type-C supported

2 LEDs indicate states

5V/1.2A Sync.

4.2V/1.2A fixed

SOT23-5

PowerSOC+,3 in 1,auto charge or discharge

移动电源，后备系统供电，强光手电筒

ETA6185

2 in 1,work with MCU

Defined by MCU

5V/2.5A Sync.

4.35V/3A adj

QFN3x3-20

PowerSOC+,2 in 1,work with MCU

移动电源，苹果、安卓背夹等

ETA6193

3 in 1,Type-C supported

2 LEDs indicate states

5V/1.2A Sync

4.35V/1.2A fixed

SOT23-5

PowerSOC+,3 in 1,auto charge or discharge

移动电源，后备系统供电，强光手电筒

ETA6850

3 in 1,Type-C supported

4 LEDs indicate states

4.5-12V Sync

4.2V/4.35V/4A max

QFN4x4-32

PowerSOC+,3 in 1,QC/SCP/AFC/FCP fastcharge

快充移动电源，自带QC输入，可配合快充协议输出

ETA6884

3 in 1,auto start discharge

4 high accuracy LEDs

5V/2.4A Sync.

4.2V/4.35V/3A adj

QFN4x4-28

PowerSOC+,3 in 1,auto start discharging

移动电源

ETA6886

3 in 1,start by manual

4 high accuracy LEDs

5V/2.4A Sync.

4.2V/4.35V/3A ad

QFN4x4-28

PowerSOC+,3 in 1,start by manual pressing

移动电源

ETA6887

3 in 1,start by manual

4 high accuracy LEDs

5V/2.4A Sync.

4.2V/4.35V/3A adj

QFN4x4-28

PowerSOC+,3 in 1,iphone power case

移动电源，苹果、安卓背夹等

ETA6980

3 in 1,auto start discharge

4 high accuracy LEDs

5V/2.4A Sync.

4.2V/3A adj

QFN4x4-28

PowerSOC+,3 in 1,high efficiency

高性能移动电源

ETA6982

3 in 1,auto start discharge

4 high accuracy LEDs

5V/2.4A Sync

4.2V/3A adj

QFN3x3-20

PowerSOC+,3 in 1,high efficiency turbo

高性能移动电源

ETA6983

3 in 1,auto start discharge

4 high accuracy LEDs

5V/3.1A Sync

4.2V/3A adj

QFN3x3-20

PowerSOC+,3 in 1,high efficiency turbo

高性能移动电源

ETA6986

2 in 1,work with MCU

Chrg LED,MCU defined

5V/3A Sync

4.2V/4.35V/5A ad

QFN3x3-20

PowerSOC+,2 in 1,work with MCU

移动电源，苹果、安卓背夹等

ETA9638

2 in 1,with charger LED

Chrg LED,MCU defined

5V/1A Sync

4.2V/1A linear

ESOP8

PowerSOC+,2 in 1,work with MCU

移动电源，蓝牙充电盒，系统后备供电

ETA9640

3 in 1,linear charger

Heartbeat LED

5V/1A Sync.

4.2V/1A linear

ESOP8

PowerSOC+,2 in 1,work with MCU

移动电源，蓝牙充电盒，系统后备供电

ETA9697

2 in 1,work with MCU

Chrg LED,MCU defined

5V/0.4A Sync.

4.2V/1.2A linear

ESOP8

PowerSOC+,2 in 1,work with MCU

移动电源，蓝牙充电盒，系统后备供电

ETA9720

3 in 1,Type-C supported

4 LEDs indicate states

5V/1.2A Sync.

4.2V/1.2A adj

SOP8

PowerSOC+,3 in 1,auto charge or discharge

移动电源

ETA9740

3 in 1,Type-C supported

4 LEDs indicate states

5V/2.4A Sync.

4.2V/3A adj

ESOPR

PowerSOC+,3 in 1,auto charge or discharge

移动电源

ETA9741

3 in 1,Flash supported

4 LEDs indicate states

5V/2.4A Sync

4.2V/2A fixed

ESOP8

PowerSOC+,3 in 1,auto charge or discharge

带手电筒的移动电源

ETA9742

3 in 1,MCU supported

4 LEDs indicate states

5V/2.4A Sync

4.2V/3A adj

ESOP8

PowerSOC+,3 in 1,auto charge or discharge

数码管的移动电源

ETA9880

3 in 1,auto start discharge

4 high accuracy LEDs

5V/2.4A Sync

4.2V/4.35V/2.4A fixed

ESOP8

PowerSOC+,3 in 1,high efficiency

高性能移动电源

ETA9881

3 in 1,auto start discharge

4 high accuracy LEDs

5V/2.4A Sync

4.2V/4.35V/2.4A fixed

ESSOP10

PowerSOC+,3 in 1,high efficiency,D+/D-

高性能移动电酒

ETA9882

2 in 1,with charger LED

Chrg LED,MCU defined

5V/2.4A Sync

4.2V/4.35V/2.4A fixed

ESSOP10

PowerSOC+,3 in 1,high efficiency

高性能移动电源

ACDC 控制器

Part Nd

Descriptior

lopology

REE

cCN

standhv

Package

Commen

备注

ETA7901

QuickCharger ProtocolController

Single USB-A port

FB control

Linear

no limit

SOT23-6

For QC ACDC Charger,Car Charger

QC2.0/3.0,FSP,SCP,AFC,Apple2.4A,BC1.2,VOOC

ETA7913

QC and PD Protocol Controller

A+C dual port

FB control

Linear

no limit

TSSOP16

For QC/PD ACDC Charger,Car Charger

PD3.0,PPS,QC2.0/3.0,FSP,SCP,AFC,Apple2.4A,BC1.2VOO

ETA7915

QC and PD Protocol Controller

Single TypeC port

FB control

Linear

no limit

TSSOP16

For QC/PD ACDC Charger,Car Charger

PD3.0,PPS,QC2.0/3.0,FSP,SCP,AFC,Apple2.4A,BC1.2,VOO

ETA8047

SSR PWM Controller

Flyback

QR/CCM

80K

<75

<50

Yes

SOT23-6

OB2362L compatible

普通中功率电源适配器及电源系统

ETA8048

SSR PWM Controller

Flyback

QR/CCM

80K

<75

<50

Yes

SOT23-6

Constand power operation

恒功率电源适配器专用

ETA8049

SSR PWM Controller

Flyback

DCM/CCM

70K

<75

<65

Yes

SOT23-6

OB2281 compatible

普通中功率电源适配器及电源系统

ETA8051

SSR PWM Controller

Flyback

QR/CCM

80K

<75

<15

Yes

SOP-7

Integrated,1.3ohm/700V Power Mosfet

系统待机电源及小功率电源系统专用

ETA8056

SSR PWM Controller

Flyback

QR/CCM

80K

<75

<20

Yes

SOP-7

Integrated,1.2ohm/650V Power Mosfet

20W PD/QC电源适配器专用

ETA8058

SSR PWM Controller

Flyback

QR/CCM

80K

<75

<27

Yes

SOP-7

Integrated,0.76ohm/650V Power Mosfet

22.5/24W PD/QC电源适配器专用

ETA8059

SSR PWM Controller

Flyback

QR/CCM

80K

<75

<30

Yes

DFN5x6-7

Integrated,0.52ohm/650V Power Mosfet

27/30W PD/QC电源适配器专用

ETA8075P30

SSR PWM controller

Flyback

QR/DCM

110K

<75

<45

Yes

SOT23-6

High frequency,QR CC/CP/CV operation

30W PD快充超结MOS绕线变压器电源

ETA8075P45

SSR PWM controller

Flyback

QR/DCM

110K

<75

<65

Yes

SOT23-6

High frequency,QR CC/CP/CV operation

45/60W PD快充超结MOS绕线变压器电源

ETA8076P30

SSR PWM controller

Flyback

QR/DCM

130K

<75

<45

Yes

SOT23-6

High frequency,QR CC/CP/CV operation

30W PD快充平面变压器氮化镓MOS电源

ETA8076P45

SSR PWM controller

Flyback

QR/DCM

130K

<75

<65

Yes

SOT23-6

High frequency.QR CC/CP/CV operation

45/60W PD快充平面变压器氮化镓MOS电源

ETA8076P60

SSR PWM controller

Flyback

QR/DCM

130K

<75

<65

Yes

SOT23-6

High frequency,QR CC/CP/CV operation小于65W恒流LED电源

TWS IC

Part Nd

Description

ndicato

Boost

Charge

Toleration(V

Packags

Comment

备注

ETA9084

3 in 1,charger+boost+fuel gauge

4 LEDs fuel gauge

5V/0.5A Sync

4.2V/4.35V/1A adj

ESSOP10/DFN3x3-10

20V Vin standoff low IQ charger+boost

蓝牙充电盒，移动电源，4.2V/4.35V截止电压

ETA9085

3 in 1,charger+boost+fuel gauge

4 LEDs fuel gauge

5V/0.5A Sync

4.2V/4.35V/1A adj

ESSOP10/DFN3x3-10

20V Vin standoff,low IQ charger+boost

蓝牙充电盒，移动电源，4.2V/4.35V截止电压

ETA9184

3 in 1,charger+boost+fuel gauge

4 LEDs fuel gauge

5V/1A Sync

4.2V/4.35V/1A adj

ESSOP10/DFN3x3-10

20V Vin standoff,low IQ charger+boost

蓝牙充电盒，移动电源，4.2V/4.35V截止电压

ETA9185

3 in 1,charger+boost+fuel gauge

4 LEDs fuel gauge

5V/1A Sync

4.2V/4.35V/1A adj

ESSOP10/DFN3x3-10

20V Vin standoff low IQ charger+boost

蓝牙充电盒，移动电源，4.2V/4.35V截止电压

ETA9695

2 in 1,<5uA standby current

2 LEDs fuel gauge

5V/0.4A Sync

4.2V/1.2A ad

ESOP8

16V Vin standoff,low IQ charger+boost

蓝牙充电盒，移动电源，4.2V截止电压

ETA9697

2 in 1,<5uA standby current

2 LEDs fuel gauge

5V/0.4A Sync

4.2V/1.2A adj

ESOPR

16V Vin standoff,low IQ charger+boost

蓝牙充电盒，移动电源，4.2V截止电压

ETA96973

2 in 1,<5uA standby current

2 LEDs fuel gauge

5V/0,4A Sync

4.35V/1.2A ad

ESOP8

16V Vin standoff low IQ charger+boost

蓝牙充电盒，移动电源，4.35V截止电压

ETA9698

2 in 1,<5uA standby current

2 LEDs fuel gauge

5V/0.4A Sync

4.2V/1.2A adj

ESOP8

40V Vin standoff,low IQ charger+boost

蓝牙充电盒，移动电源，4.2V截止电压

ETA9797

2 in 1,<5uA standby current

2 LEDs fuel gauge

5V/0.4A Sync

4.2V/1.2A adj

ESOP8

16V Vin standoff low IQ charger+boost

蓝牙充电盒，移动电源，4.2V截止电压

ETA9897

2 in 1,<3uA standby current

21EDs fuel gauge

5V/0.4A Sync

4.2V/1.2A adj

ESOP8

30V Vin standoff low IQ charger+boost

蓝牙充电盒，移动电源，4.2V截止电压

过压保护器

Part No

Description

Vin
RangeN

Switch
Rdson(mo

kesponse
ime(ns

OVP
1Bv

Package

Comment

备注

ETA4034

30V/2A OVP+OCP

3.5-30

130

Fix_6.15

DFN2x2-8

ILIM adjustable,fast response time

快速响应，限流可调，NTC温度检测

ETA6121

32V/30m52 high side over voltage protector

3.5-20

100

1.21

CSP3x4-12

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应，

兼容FPF2280/RT9746

ETA6122

32V/45mΩ high side over voltage protector

4.1-28

1.2

CSP2x3-6/SOT23-5

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应，兼容ET9523

ETA6123

26V/40m52 high side over voltage protector

4.1-24.5

Fix_5.85

FCQFN1.2x1.2-9/SOT239-6

with 80V TVS,Fast response time

快速响应，内置80V TVS,多个过压保护点可选

ETA7008

36V/34mΩ low side over voltage protector

2-36

100

0.5

SOT23-6/DFN2x2-6

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

ETA7011

20V/10mΩ(40mQ)high side over voltage protector

3.35-20

40/10

100

1.26

SOT23-6

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

ETA7014

36V/35mΩ high side over voltage protector

3.35-36

100

1.26

SOT23-6/DFN2x2-8

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

ETA7016

36V/33mΩ high side over voltage protector w.500V 7V TVS

3.35-7

100

1.26

DFN3x3-12

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

ETA7018

20V/12mΩ low side over voltage protector

5-20

100

0.5

SOT23-6

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

ETA7024

50V/40mΩ high side over voltage protector

4.5-50

200

1.26

SOP7

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

ETA7028

36V/30mΩ low side over voltage protector

3.6-36

1.27

SOT23-6

OVP level adjustable,Fast response time

过压保护点可调，高耐压，低内阻，快速响应

LED 驱动

Part Nc

Descriptior

Architecture

Vin Range(V

Max No.of LEDs

Max lsw(A)

Wfb(V

Frequency(Hz

lq(uA

Package

Min Dimming Duty

备注

ETA1165

2x10 LEDs Driver

Non-Sync.Boost

2.7-6

0.7

0.2

600K

600

SOT23-6

高效单串可驱动10颗LED,兼容TPS61165

ETA1168

x10 LEDs Driver

Non-Sync.Boost

2.7-6

0.7

0.2

600K

600

DFN2x2-6

高效单串可驱动10颗LED,兼容TPS61161

ETA1611

16x6 LEDs Driver

Non-Sync.Boost

2.7-6

2.8

0.2

250

SOT23-6

超大屏背光，手持大功率LED照明

ETA1617

General LED Driver

Non-Sync.Boost

2.7-6

0.2

800K

200

SOT23-6

通用手机和平板7.9寸TFT屏背光

ETA1627

2x10 LEDs Driver

Non-Sync.Boost

2.7-6

800K

300

SOT23-6

优异调光性能，LED灯串联短路保护

ETA1637

30V/50mA LED Driver

Sync.True Shutoff

2.7-6

1.5

600K

300

SOT23-6

0.1%

可步真关断背光LED 驱动周光精

ETA1638

30V/50mA LED Driver

Sync.True Shutoff

2.7-6

1.5

600K

300

DFN2x2-6

0.1%

同步真关断背光LED驱动，调光精度0.1%

ETA2840

LED Lighting Driver

Non-Sync.Buck

4.5-36

up to gw

1.5

0.16

650K

500

SOT23-6

dimming at FB pin

EN回滞可接光敏电阻，降压高效照明

ETA3300

6 LEDs Driver

Non-Sync.Boost

2-6

1.6

0.2

500K-3M

SOT23-6

高效单串可驱动6颗LED

ETA3421

IR LED Driver

Sync.Buck

2.5-6.5

1.1

0.1

1.5M

SOT23-5

同步降压IR LED驱动，电流可调，兼容PAM2804

ETA6011

1 LED Driver

Linear

2.5-5.5

2.2

Linear

120

ESOP8

大功率线性LED驱动器，强光手电筒

ETA6012

High brightness LED Driver

Linear

2.1-6

2.2

Linear

100

ESOP8

恒温电流控制，高亮度LED,兼容CN5711

	低压差线性稳压器
注：添加“*“含有更多型号，具体可联系ETA人员
Part Ng		Description	Architecture	Vin MinV	Vin MaxM)	Vout Min(M)	Vout Max(M)	lout Max(m4	Vfb(V)	lq(uA	Package	Comment	备注
+FTA502C		300mA LDO	Linear	1.6	6	0.8	3.95	300	Fixed	35	SOT23-3	Vout fixed,70dB PSRR,low noise	输出固定电压，多电压版本可选，通用LDO
*ETA5040		45V LDO	Linear	3	45	1.2	20	300	Fixed	2.5	SOT23-5/DFN1.6x1.6-6	Vout fixed,70dB PSRR,wide input voltage	输出固定电压，输入高压，超低功耗，兼容RT9069
*ETA5041		45V LDO	Linear	3	45	1.2	20	300	1	2.5	SOT23-5	70dB PSRR,wide input voltage	多输出电压版本可选，输入高压，超低功耗
*ETA5043		45V LDO	Linear	3	45	1.2	20	300	Fixed	2.5	SOT23-5	Vout fixed,70dB PSRR,wide input voltage	输出固定电压，输入高压，超低功耗，兼容WL2851
ETA5050		500mA LDO	Linear	2	6	0.8	6	500	0.8	37	SOT23-5	Vout adjustable,high PSRR,low noise	输出电压可调，通用LDO,兼容LM3985/NCP114
*ETA5051		300mA LDO	Linear	2.7	5.5	1.8	3.3	300	Fixed	170	SOT23-5	Vout fixed,80dB PSRR,low noise	输出固定电压，通用LDO,兼容TPS793xx
ETA5052		300mA LDO	Linear	2.7	5.5	1.2	5.5	300	1.2	170	SOT23-6	Vout adjustable,80dB PSRR,low noise	输出电压可调，通用LDO,兼容TPS79301
*ETA5053		300mA LDO	Linear	1.6	6	0.8	3.95	300	Fixed	35	SOT23-5/DFN1x1-4	Vout fixed,70dB PSRR,low noise	超小封装，平板/OTT等，兼容AP7374D
*ETA5055		High PSRR,.500mA LDO	Linear	1.8	5.5	1.1	3.6	500	Fixed	4.5	SOT23-5/DFN1x1 A/DFN2x2-6	Vout fixed,102dB high PSRR,low noise	输出固定电压，通用LDO,兼容NCP160
ETA5057		Low noise,350mA LDO	Linear	2.7	5.5	1.2	5.5	350	1.2	170	SOT353-5	Vout adjustable,80dB PSRR,low noise	输出电压可调，通用LDO,兼容TPS71701
*ETA5060		1A LDO	Linear	1.8	5.5	0.8	5	1000	0.8	20	SOT89-5/DFN1.2x1.6- 8/DFN2x2-8	1A,high PSRR,low lq	多输出电压版本可选，通讯等应用，兼容NCP186
*ETA5070		Ultra-low lq,150mA LDO	Linear	2.2	7	1.2	3.6	150	Fixed	0.7	SOT23-5/DFN1x1-4	Vout fixed,low lq for cellphones, wearable	超低功耗，手机/穿戴设备，兼容RT9078
*ETA5071		Ultra-low Iq,300mA LDO	Linear	1.8	6.5	1.2	3.6	300	Fixed	1	SOT23-5/DFN1x1-4	Vout fixed,88dB PSRR,low Iq for cellphones,wearable	超低功耗，手机/穿戴设备，兼容RT9078
*ETA5094		40V,150mA LDO	Linear	6	40	3.3/5	3.3/5	150	Fixed	75	SOT89-3	Vout fixed,Low noise,low lq	应用于各类高耐压场合，低功耗
*ETA5095		40V,150mA LDO	Linear	6	40	1.5	24	150	1.1	75	SOT23-5/SOT89-3	Vout adjustable,Low noise,low lq	应用于各类高耐压场合，低功耗
ETA5096		12V Power Switch+LDO	Linear	5	16	1.1	16	240	1.1	130	SOT23-6/SOP8	VLDO adjustable,Vdppm fixed 12V	应用于电表等12V供电接口，并含1路Load switch
ETA5097		12V Power Switch+LDO	Linear	5	16	1.1	16	250	1.1	140	SOT23-6/SOP8	VLDO adjustable,Vdppm fixed 12V	应用于电表等12V供电接口，并含1路Load switch
ETA5098		12V Power Switch+LDO	Linear	5	16	1.1	16	240	1.1	150	SOP8	VLDO adjustable,Vdppm fixed 12V	应用于电表等12V供电接口，并含1路Load switch
*ETA5120		20V LDO	Linear	2.5	20	1.2	5	200	Fixed	2	SOT23-5	Vout fixed,low lq,wide inout voltage	输出固定电压，输入高压，超低功耗
*ETA5122		20V LDO	Linear	2.5	20	1.2	5	200	Fixed	2	SOT89-5	Vout fixed,low lq,wide inout voltage	输出固定电压，输入高压，超低功耗
*ETA5196		24V Power Switch+LDO	Linear	3.8	24	1.1	12	200	1.1	100	SOT23-6/SOP8	current limit switch+LDO	应用于电表等12V供电接口，并含1路Load switch
ETA5197		24V Power Switch+LDO	Linear	3.8	24	1.1	12	200	1.1	100	SOT23-6	current limit switch+LDC	应用于电表等12V供电接口，并含1路Load switch
ETA5198		30V Power Switch+LDO	Linear	3.8	30	1.1	30	200	1.1	100	ESOP8	current limit switch+LDC	应用于电表等12V供电接口，并含1路Load switch
*ETA5254		Dual 300mA LDO	Linear	1.6	6	0.8	3.95	300	Fixed	35	SOT23-6	Vout fixed,60dB PSRR,low noise	两路LDO,输出固定电压
ETA9297		12V Power Switch+LDO	Linear	5	16	1.1	16	400	1.1	300	SOP8	VLDO adjustable,Vdppm fixed 12V	应用于电表等12V供电接口，并含1路Load switch

电压电平转换器

Part Nc

Description

Channe

Push-pul
dete rate Ma

O0en-drair
iate rate Wr

nort

B ports
Woltage(V)

Package

Commen

备注

ETA4553

2-bit bidirectional voltage-level translator

2bits

90Mbps

2Mbps

1.65-5.5

2.3-55

DFN1.4x1.0-8/DFN 2x2-8

2bits,push-pull/open-drain

2通道电平转换，应用于1.8V,2.5V,3.3V,5V逻辑系统

ETA4554

4-bit bidirectional voltage-level translator

4bits

90Mbps

2Mbps

1.65-5.5

2.3-5.5

QFN2x2-14/TSSOP-14/QFN1.7x2-12/QFN3x3-
16/QFN3.5x3.5-14

4bits,push-pull/open-drain

4通道电平转换，应用于1.8V,2.5V,3.3V,5V逻辑系统

ETA4555

8-bit bidirectional voltage-level translator

8bits

100Mbps

2Mbps

1.65-5.5

2.3-5.5

QFN4.5x3.5-20/TSSOP-20

8bits,push-pull/open-drain

8通道电平转换，应用于1.8V,2.5V,3.3V,5V逻辑系统

ETA4573

2-bit bidirectional voltage-level translator

2bits

≥100Mbps

1.2-5.5

1.65-5.5

DFN1.4x1.0-8/SOT23-8

2bits,push-pull,high speed

2通道电平转换，应用于1.2V,1.5V,1.8V,2.5V,3.3V,5V逻辑系

ETA4574

4-bit bidirectional voltage-level translator

4bits

≥100Mbps

1.2-5.5

1.65-5.5

QFN2x2-14/TSSOP-14/QFN1.7x2-12/QFN3x3-
16/QFN3.5x3.5-14

4bits,push-pull high speed

4通道电平转换，应用于1.2V,1.5V,1.8V,2.5V,3.3V,5V逻辑系统

ETA4575

8-bit bidirectional voltage-level translator

8bits

≥100Mbps

1.2-5.5

1.65-5.5

QFN4.5x3.5-20/TSSOP-20

8bits,push-pull,high speed

8通道电平转换，应用于1.2V,1.5V,1.8V,2.5V,3.3V,5V逻辑系统

电池均衡器

Part No

Description

Architecture

Vin Min(V)

Vin Max(M)

No.of batts

No.of ICs

Balance
Currentl

Accurate(mV

switching
Frequency(Hz

lq(uA

Packag

Comment

ETA3000

Active cell balancer

Sync

3.75

n(non-limited)

n-1

SOT23-6/DFN2x2-8

Not limit the No.s of
batteries,support all
battery types

ETA3001

Active cell balance controller

Sync

3.75

n(non-limited)

n-1

DFN2×2-8

Not limit the No.s of
batteries,support all
battery types

无线充功率IC

Part Nc

Description

Architecture

Vin Min(V)

Nin Max(V

out Max(A)

leak(uA

Enahle
contro

OTP(℃)

witching
Frequency(Hz

盟

packag

Comment

备注

ETA7522

4 PowerFets with dual half-bridges

Driver+N-MOSFET

4.2

<20

each channel

150

<350K

1.25

DFN3x3-12/ESOP-10

Wireless charger compatible

无线充，马达驱动，升降压MOS组合

ETA7523

4 PowerFets with dual half-bridges

Driver+N-MOSFET

4.3

each channel

150

<350K

0.2

QFN3x3-20

Wireless charger compatible

无线充，马达驱动，升降压MOS组合

ETA7524

4 PowerFets with dual half-bridges

Driver+N-MOSFET

1.8

each channel

150

<350K

0.016

ESOP8/DFN2x3-8

Wireless charger compatible

无线充，马达驱动，升降压MOS组合

	限流开关
Part No		Descriptior	Architecture	Win Min(V	Vin Max(V	Foldback voltage(V)	out Mak(A)	Gwitch Rdsonimd	lq(uA)	Package	comment	备注
ETA6010		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-5	ILIM adjustable,reverse blocking	限流可调，防反灌
ETA6011		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	ESOPR	ILIM adjustable,reverse blocking	限流可调，防反灌，可应用 ED恒流 FL
ETA6020		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-6/DFN2x2-6	ILIM adjustable,reverse blocking	限流可调，过流报警，防反灌
ETA6021		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-5	ILIM adjustable,reverse blocking	限流可调，防反灌
ETA6022		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	DFN2x2-6	ILIM adjustable,reverse blocking	限流可调，防反灌
ETA6023		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-5	ILIM adjustable,reverse blocking	限流可调，防反灌
ETA6024		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-6	ILIM adjustable,reverse blocking	限流可调，过流报警，防反灌
ETA6027		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-5/SOT23-6/DFN2x2-6	ILIM adjustable,reverse blocking	限流可调，过流报警，防反灌，兼容TPS2553
ETA6030		1.2A USB Power Switch	High Side Switch	8.5	24	VIN-2.5	1.2	500	100	SOT23-6	ILIM adjustable,reverse blocking	限流可调，防反灌
ETA6033		3.5A USB Power Switch	Low Side Switch	2.5	5.5	1	3.5	60	70	SOT23-6	ILIM adjustable,reverse blocking	限流可调，输入电压钳位保护
ETA6280		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-5/SOT23-6/DFN2x2-6	ILIM adjustable,reverse blocking	限流可调，过流报警，防反灌，兼容SY6280
ETA6281		2.2A USB Power Switch	High Side Switch	2.1	6	1	2.2	70	100	SOT23-5/SOT23-6/DFN2x2-6	ILIM adjustable,reverse blocking	限流可调，过流报警，防反灌

负载开关

Part Nc

Descriptior

Architecture

Vin Min(V

Win Max(V

out Max(A)

wite
Rds no

a(uA

Packag

commen

备注

ETA7015

Ultra low Ron Power Switch w.EN control and reverse
lockinc

Power Switch

3.68

160

SOT23-6/ESOPE

Giant currentand fully protection

平板、笔记本等各类电子产品

ETA7017

Ultra low Ron Power Switch w.EN control

Power Switch

1.4

5.5

0.1

WLCSP0.87x0.87-4

Ultra low quiescent,small package

NBIOT、无线模块、手持设备
兼容TPS22913/NCP334

分享到：

上一篇：没有了

下一篇：钰泰选型表
